redhat4下装了oracle，空间不够用了，在网上找了半天终于搞定
第一步：编辑vm的磁盘大小
选择磁盘编辑想改变的大小。
第二步：使用Linux下的fdisk工具进行分区
用root用户登录：
打印当前的磁盘分区表，这时我们可以看到磁盘的总量的确增加到30GB 了，但是分区只有以前的那几个原有的分区
[root@localhost ~]# fdisk -l
键入命令： fdisk /dev/sda “sda 就是经过扩容的硬盘，为 SCSI 硬盘， IDE 类型硬盘对应为 hda ，是对该硬盘进行操作 ”
选择主分区吧，则键入 p
此时， fdisk 会让你选择主分区的编号，如果已经有了主分区 sda1 ， sda2 ，那么编号就选3 ，即要创建的该分区为 sda3.
键入： 3
此时， fdisk 又会让你选择该分区的开始值这个就是分区的 Start 值（ start cylinder ）；这里最好直接按回车， 如果您输入了一个非默认的数字，可能会造成空间浪费；
对于分区的 End 值（end cylinder），同样直接按回车。这时候会显示出你新建分区的柱面范围和空间大小。
此时键入： w 表示" 保存所有并退出，分区划分完毕 "
[root@localhost ~]# fdisk /dev/sda
The number of cylinders for this disk is set to 3916.
There is nothing wrong with that, but this is larger than 1024,
and could in certain setups cause problems with:
1) software that runs at boot time (e.g., old versions of LILO)
2) booting and partitioning software from other OSs
(e.g., DOS FDISK, OS/2 FDISK)
Command (m for help): n
Command action
e extended
p primary partition (1-4)
p
Partition number (1-4): 3
First cylinder (1045-3916, default 1045):
Using default value 1045
Last cylinder or +size or +sizeM or +sizeK (1045-3916, default 3916):
Using default value 3916
Command (m for help): w
The partition table has been altered!
Calling ioctl() to re-read partition table.
WARNING: Re-reading the partition table failed with error 16: 设备或资源忙.
The kernel still uses the old table.
The new table will be used at the next reboot.
Syncing disks.
我们的新建分区/dev/sda3，却不是LVM的。所以，接下来使用fdisk将其改成LVM的。
[root@CNGI-SIP6-BUPT ~]# fdisk /dev/sda
Command (m for help): m
Command (m for help): t //改变分区系统id
Partition number (1-4): 3 //指定分区号
Hex code (type L to list codes): 8e //指定要改成的id号，8e代表LVM。
Command (m for help): w
[root@localhost ~]# fdisk /dev/sda
The number of cylinders for this disk is set to 3916.
There is nothing wrong with that, but this is larger than 1024,
and could in certain setups cause problems with:
1) software that runs at boot time (e.g., old versions of LILO)
2) booting and partitioning software from other OSs
(e.g., DOS FDISK, OS/2 FDISK)
Command (m for help): m
Command action
a toggle a bootable flag
b edit bsd disklabel
c toggle the dos compatibility flag
d delete a partition
l list known partition types
m print this menu
n add a new partition
o create a new empty DOS partition table
p print the partition table
q quit without saving changes
s create a new empty Sun disklabel
t change a partition's system id
u change display/entry units
v verify the partition table
w write table to disk and exit
x extra functionality (experts only)
Command (m for help): t
Partition number (1-4): 3
Hex code (type L to list codes): 8e
Changed system type of partition 3 to 8e (Linux LVM)
Command (m for help): w
The partition table has been altered!
Calling ioctl() to re-read partition table.
WARNING: Re-reading the partition table failed with error 16: 设备或资源忙.
The kernel still uses the old table.
The new table will be used at the next reboot.
Syncing disks.
重新登录后：
[root@localhost ~]# reboot
Broadcast message from root (pts/1) (Thu Sep 22 09:54:45 2011):
The system is going down for reboot NOW!
[root@localhost ~]# fdisk -l
Disk /dev/sda: 32.2 GB, 32212254720 bytes
255 heads, 63 sectors/track, 3916 cylinders
Units = cylinders of 16065 * 512 = 8225280 bytes
Device Boot Start End Blocks Id System
/dev/sda1 * 1 13 104391 83 Linux
/dev/sda2 14 1044 8281507+ 8e Linux LVM
/dev/sda3 1045 3916 23069340 8e Linux LVM
Disk /dev/sdb: 6442 MB, 6442450944 bytes
255 heads, 63 sectors/track, 783 cylinders
Units = cylinders of 16065 * 512 = 8225280 bytes
Device Boot Start End Blocks Id System
/dev/sdb1 1 783 6289416 83 Linux
第三步、格式化该新添加的分区
格式化磁盘
[root@localhost ~]# mkfs -t ext3 /dev/sda3
mke2fs 1.35 (28-Feb-2004)
max_blocks 4294967295, rsv_groups = 0, rsv_gdb = 1024
max_blocks 4294967295, rsv_groups = 0, rsv_gdb = 1024
warning: 167 blocks unused.
Filesystem label=
OS type: Linux
Block size=4096 (log=2)
Fragment size=4096 (log=2)
2889216 inodes, 5767168 blocks
288366 blocks (5.00%) reserved for the super user
First data block=0
Maximum filesystem blocks=8388608
176 block groups
32768 blocks per group, 32768 fragments per group
16416 inodes per group
Superblock backups stored on blocks:
32768, 98304, 163840, 229376, 294912, 819200, 884736, 1605632, 2654208,
4096000
Writing inode tables: done
inode.i_blocks = 90120, i_size = 4243456
Creating journal (8192 blocks): done
Writing superblocks and filesystem accounting information: done
This filesystem will be automatically checked every 24 mounts or
180 days, whichever comes first. Use tune2fs -c or -i to override.
第四步、扩充根分区
[root@localhost ~]# lvs
LV VG Attr LSize Origin Snap% Move Copy%
LogVol00 VolGroup00 -wi-ao 5.91G
LogVol01 VolGroup00 -wi-ao 1.94G
[root@localhost ~]# pvcreate /dev/sd
sda sda1 sda2 sda3 sdb sdb1
[root@localhost ~]# pvcreate /dev/sda3
Physical volume "/dev/sda3" successfully created
[root@localhost ~]# df -h
Filesystem 容量 已用 可用 已用% 挂载点
/dev/mapper/VolGroup00-LogVol00
5.9G 5.5G 120M 98% /
/dev/sda1 99M 9.0M 85M 10% /boot
none 506M 0 506M 0% /dev/shm
/dev/sdb1 6.0G 347M 5.3G 7% /disk2
[root@localhost ~]# vgdisplay
--- Volume group ---
VG Name VolGroup00
System ID
Format lvm2
Metadata Areas 1
Metadata Sequence No 3
VG Access read/write
VG Status resizable
MAX LV 0
Cur LV 2
Open LV 2
Max PV 0
Cur PV 1
Act PV 1
VG Size 7.88 GB
PE Size 32.00 MB
Total PE 252
Alloc PE / Size 251 / 7.84 GB
Free PE / Size 1 / 32.00 MB
VG UUID HvKxmm-WazL-TjFN-yXNH-ui8U-pcl9-Pk6psB
[root@localhost ~]# vgextend VolGroup00 /dev/sda3
Volume group "VolGroup00" successfully extended
[root@localhost ~]# vgdisplay
--- Volume group ---
VG Name VolGroup00
System ID
Format lvm2
Metadata Areas 2
Metadata Sequence No 4
VG Access read/write
VG Status resizable
MAX LV 0
Cur LV 2
Open LV 2
Max PV 0
Cur PV 2
Act PV 2
VG Size 29.88 GB
PE Size 32.00 MB
Total PE 956
Alloc PE / Size 251 / 7.84 GB
Free PE / Size 705 / 22.03 GB
VG UUID HvKxmm-WazL-TjFN-yXNH-ui8U-pcl9-Pk6psB
#不能把 Free PE / Size 705 / 22.03 GB的空间全部加上，应该下雨22.03
[root@localhost ~]# lvextend -L+22.03G /dev/VolGroup00/LogVol00 /dev/sda3
Rounding up size to full physical extent 22.03 GB
Extending logical volume LogVol00 to 27.94 GB
Insufficient allocatable logical extents (893) for logical volume LogVol00: 894 required
[root@localhost ~]# lvextend -L+21.03G /dev/VolGroup00/LogVol00 /dev/sda3
Rounding up size to full physical extent 21.03 GB
Extending logical volume LogVol00 to 26.94 GB
Logical volume LogVol00 successfully resized
[root@localhost ~]# cat /etc/fstab
# This file is edited by fstab-sync - see 'man fstab-sync' for details
/dev/VolGroup00/LogVol00 / ext3 defaults 1 1
LABEL=/boot /boot ext3 defaults 1 2
none /dev/pts devpts gid=5,mode=620 0 0
none /dev/shm tmpfs defaults 0 0
none /proc proc defaults 0 0
none /sys sysfs defaults 0 0
/dev/VolGroup00/LogVol01 swap swap defaults 0 0
/dev/sdb1 /disk2 ext3 defaults 1 1
/dev/hdc /media/cdrom auto pamconsole,exec,noauto,managed 0 0
/dev/fd0 /media/floppy auto pamconsole,exec,noauto,managed 0 0
[root@localhost ~]# e2fsck -a /dev/VolGroup00/LogVol00
/dev/VolGroup00/LogVol00 is mounted.
WARNING!!! Running e2fsck on a mounted filesystem may cause
SEVERE filesystem damage.
Do you really want to continue (y/n)? yes
/dev/VolGroup00/LogVol00: recovering journal
/dev/VolGroup00/LogVol00: Clearing orphaned inode 596983 (uid=501, gid=501, mode=0100660, size=0)
/dev/VolGroup00/LogVol00: clean, 144094/774144 files, 1440278/1548288 blocks
#redhat4 没有resize2fs命令
[root@localhost ~]# resize2fs
-bash: resize2fs: command not found
#redhat4下用ext2online
[root@localhost ~]# ext2online /dev/VolGroup00/LogVol00
ext2online v1.1.18 - 2001/03/18 for EXT2FS 0.5b
[root@localhost ~]# df -h
Filesystem 容量 已用 可用 已用% 挂载点
/dev/mapper/VolGroup00-LogVol00
27G 5.5G 20G 22% /
/dev/sda1 99M 9.0M 85M 10% /boot
none 506M 0 506M 0% /dev/shm
/dev/sdb1 6.0G 347M 5.3G 7% /disk2
现在大公告成
